Description
Console Suspension Pulley – Safe Load Handling for Formwork & Scaffolding
The Console Suspension Pulley, also known as the Console Lifting Pulley, is an essential accessory for safe load handling and movement in scaffold and formwork systems. Integrated into climbing formwork and tunnel formwork structures, it ensures that loads are transported and directed in a balanced and controlled manner.
Key Features
✅ Durable Material – Manufactured from high-strength steel with heavy load-bearing capacity.
✅ Safe Usage – Securely mounted to the formwork, providing maximum safety and stability.
✅ Easy Installation – Quick to assemble and adaptable to different formwork and scaffolding systems.
✅ Long-Lasting – Coated for rust and wear resistance, ensuring extended service life.
Areas of Application
The Console Lifting Pulley is widely used in climbing formwork systems, tunnel formwork, and large-scale construction projects. It helps create a safer and more efficient working environment, making it a preferred choice in Gulf region construction markets, including the UAE, Qatar, Saudi Arabia, Kuwait, Oman, and Bahrain.
Custom Production
We also provide tailor-made solutions for custom sizes, meeting the specific requirements of your projects in the Middle East and Gulf countries.
Technical Specifications
| Article No. | Bar Ø (mm) | Ø1-Ø2-Ø3 (mm) | Length (mm) | Weight (kg/pcs.) |
|---|---|---|---|---|
| UMT-R M20x35 | M20–M24 | 65–35–55 | 35 | 0.5 |
| UMT-R M24x35 | M24–M30 | 70–35–58 | 70 | 0.9 |
| UMT-R M30x48 | M24–M30 | 90–48–90 | 53 | 1.4 |
