Description
Areas of Use – Carrot Anchor System
Our removable anchoring system, widely known in construction sites as the “Carrot Anchor”, is highly preferred in major infrastructure and building projects across the Gulf region (UAE, Qatar, Saudi Arabia, Kuwait, Oman, Bahrain).
Main Application Areas
Dams and hydroelectric power stations
Viaducts and bridge constructions
High-rise buildings and retaining walls
Highway safety barriers
Precast concrete elements for factories
Cable tensioning systems
Removability & Cost-Effectiveness
Thanks to its reusable and durable structure, the Carrot Anchor provides an economical solution for concrete and formwork applications.
For easy removal, the anchor must be lubricated before use.
In high-strength concrete applications, wrapping the anchor with stretch film or a protective layer after lubrication allows for effortless extraction.
This makes it an ideal choice for construction companies and contractors in the Gulf, looking for cost-effective and long-lasting anchoring solutions.
Custom Production
We also provide tailored solutions for custom sizes and project-specific requirements, ensuring maximum compatibility with your construction needs.
Technical Specifications
| Article No. | Anchor (mm) | Ø (mm) | Length (mm) | Weight (kg/pcs.) |
|---|---|---|---|---|
| UMT-M20x200 | M20 | 39 | 200 | 1.0 |
| UMT-M20x250 | M20 | 39 | 250 | 1.1 |
| UMT-M24x200 | M24 | 49 | 200 | 1.4 |
| UMT-M24x250 | M24 | 49 | 250 | 1.7 |
| UMT-M24x280 | M24 | 49 | 280 | 1.8 |
| UMT-M24x300 | M24 | 49 | 300 | 1.9 |
| UMT-M30x360 | M30 | 59 | 360 | 3.7 |
| UMT-M30x430 | M30 | 59 | 430 | 4.0 |
| UMT-M36x430 | M36 | 69 | 430 | 5.0 |
| UMT-M36x590 | M36 | 69 | 590 | 7.2 |
